PREASSEMBLED SIMPLE SUPPORT BRACKET WITH 3-1/2” DEEP MULTIGANG MASONRY BOX-SSB-MB6
$49.82
Ssb-T5 + Mb-6 + Umaa
- Description
- Additional information
- Reviews (0)
Description
| Category | SWITCH BOX | |
| Page | P1-P8 | |
| Description: | ||
| Orbit’s SSB-MB Series is the fastest and most versatile method to mount 3-1/2” deep Masonry Boxes between stud cavities. The SSB-MB is a preassembled Simple Support Bracket with three to six gang deep Masonry Box installed. The box depth is set at 5/8”, but easily adjustable to 1-1/2” via the outside adjustment screws. With 6-way adjustability, the SSB-MB series will ensure a flush finish every time. | ||
| Features: | ||
| – Simple Support Bracket adjusts from 15″ to 25″ – Maintains rigidity when fully extended, eliminating need for back support – Ships preassembled with box depth set at 5/8”, and adjustable up to 1-1/2” – Guided-slots on each side allow the box depth to be easily adjusted by simply loosening the screws – Built-In Adapter allows Masonry Box be moved along Simple Support Bracket until setting in final position with a tek screw – All Knockouts are Concentric 1/2″ & 3/4″ |
||
| Specifications: | ||
| Material | Sheet Steel | |
| Color | Galvanized | |
| Packaging Info: | ||
| Std Pkg | 10 | |
| Certifications: | ||
  |
||
| UL File Number: | ||
| E227970 | ||
| Literature | ||
Catalog
|
UPC |
No. of
|
KO Ends |
KO Botton |
KO Sides |
Cu. Inch |
| SSB-MB3 | 8-35243-02546-2 | 3 | (6) – CKO | (3) – CKO | (4) – CKO | 69.3 |
| SSB-MB4 | 8-35243-02547-9 | 4 | (8) – CKO | (4) – CKO | (4) – CKO | 92.1 |
| SSB-MB5 | 8-35243-02548-6 | 5 | (10) – CKO | (5) – CKO | (4) – CKO | 116.1 |
| SSB-MB6 | 8-35243-02549-3 | 6 | (12) – CKO | (6) – CKO | (4) – CKO | 139 |
Additional information
| Weight | 38.99 kg |
|---|
