2-1/2” DEEP, 4-11/16” SQUARE (5S) LARGE CAPACITY BOX WELDED WITH 3/4”, 1” & 1-1/4” MKO
$7.47
5S Box 2-1/2″ Deep 1″&1-1/4″ Mko
- Description
- Additional information
- Reviews (0)
Description
| Category | SWITCH BOX | |
| Page | P28 | |
| Barcode | 8-35243-01442-8 | |
| Features: | ||
| – Raised Ground Emboss – Two #8-32 x 1/2″ Mounting Screws – Suitable for Datacom & Electrical Applications – Ideal for use with SSB System when 1-1/4″ K.O. required For a 5″ square box version, please see T5B-200. |
||
| Dimensions: | ||
| Width | 4-11/16″ | |
| Height | 4-11/16″ | |
| Depth | 2 – 1/2″ | |
| Cu In | 49.4 | |
| Specifications: | ||
| Material | 16 GA Sheet Steel | |
| Mfg. Process | Welded | |
| Color | Galvanized | |
| KO Sides | (4) – 3/4″&1″ MKO, (4) – 1″&1-1/4″ MKO | |
| KO Bottom | (2) – 1/2″, (2) – 3/4″ | |
| Packaging Info: | ||
| Std Pkg | 24 | |
| Weight | 29 lbs | |
| Certifications: | ||
  |
||
| UL File Number: | ||
| E227970 | ||
| Literature | ||
Additional information
| Weight | 29.56 kg |
|---|
