HEAVY DUTY T-GRID BOX HANGERS
$9.29
Heavy Duty T-Grid Box Hanger,24″T-Grid Span,2-1/8″Box W/Ring
- Description
- Additional information
- Reviews (0)
Description
| Category | FASTENER |
| Page | F29 |
| Description: | |
| Orbit Industries’ Heavy Duty T-Grid Box Hangers are a fast and easy way to support electrical boxes in drop ceilings. The BHT-1H Series requires no tools to install, and accommodates multiple junction boxes with bottom knockouts. Standard hangers are suitable for 1-1/2” and 2-1/8” deep boxes. BHT-1HDEEP includes extension brackets to accommodate 2-1/8” deep boxes with 1-1/2” extensions. BHT-1H Series includes a box mounting clip which can provide independent support from the mounting clip or hanger. | |
| Features: | |
| – Pre-galvanized steel hanger and extension brackets – BHT-1HD & BHT-1HDEEP include spring steel box mounting clip (BHT-HD-C) – For 1-1/2”, 2-1/8” & 3-5/8” (BHT-1HDEEP) deep boxes with bottom KOs – No tools needed for installation – Accommodates multiple junction boxes – Mounts flush with face of tile – 50 lbs. static load rating |
|
| CAT NO | UPC | DESCRIPTION | STD PKG |
| BHT-1HD | 8-35243-02628-5 | 24” Heavy Duty T-Grid Box Hanger for use with boxes 1-1/2” or 2-1/8” Deep. Monting Clip included | 25 |
| BHT-1HDEEP | 8-35243-02629-2 | 24” Heavy Duty T-Grid Box Hanger for use with boxes 1-1/2”, 2-1/8” or 3-5/8″ Deep. Monting Clip and 1-1/2″ Extension Brackets included | 25 |
| BHT-HD-C | 8-35243-04073-1 | Additional box clip for use with BHT-1HD & BHT-1HDEEP | 100 |
| BHT-HD-EXT | 8-35243-04074-8 | Extension Bracket for use with BHT-1HD | 100 |
Additional information
| Weight | 19.89 kg |
|---|
